| YGL-80R drilling rig designed by WUXI JINFAN DRILLING EQUIPMENT CO., LTD has been exported to Columbia at the end of last year .Recently, the customer sent us the mail and reflected that the machine is running on very well at some different construction sites . We our company are very delighted about this news, as the customer’s approve is always our best pursuit. This news has made a great encouragement for our whole staff and we should also make persistent efforts to strive for further improvements. YGL-80R drilling rig is a kind of track chassis drilling machine with full hydraulic power head drive. It is multifunctional and various usage, especially for geothermal borehole. It is also applied in the big tonnage stress anchoring hole for water reservoir, railway and highway; the high-pressure jet grouting hole in the gravel land and also the demolishing hole of construction. 3. Main Technical Specifications 1. Drill depth ….…………………………………………… 80～100m； 2. Drill diameter ………..……………………...................... Ф220～130mm； 3. Drill rod ………………………………………………… Ф89×1500mm； 4. Drill angle range …………………………….. …………0-120°； 5. Output rotary speed of power head (rotate/reverse)…….. 5—180rpm； 6. Rating output torque of power head ….………………….. 3500Nm； 7. Feeding stroke of power head...………………………….. 1800mm； 8. Sliding stroke of mast ………………..………………….. 500mm； 9. Max. Lifting capability of power head………….…….…. 45kN； 10. Max. Thrust force of power head ………………….……. 30kN； 11. Max. Inner diameter of clamp …….…………………….. 185mm 12. Platform turning range ……..…………………………… 360° 13. Climb ability ………………….……………….………… 20° 14. Walking speed ………….……………………………..… 1.5km/h 15. CUMMINS diesel power ………………..……………… 70kw 16. Length × Width × Height (reduce) ……….. 2800mm×2000mm×2200mm 17. Total weight …………………..………………………….. 3800kg |
 |
|
YGL-80R drilling rig is under the construction in Colombia.
|
|
|
|
|
|
YGL-80R drilling rig is under the construction in Colombia
|
