| Opening diameter(mm) | ￠130 |
| drill pipe diameter(mm) | ￠89 or ￠108 |
| hole depth(m) | 30～50 |
| Power head output speed(rpm) | 0～40（stepless speed change） |
| High torque of the power head(Nm) | 2500 |
| Power head enhancement capability(kN) | 30 |
| Power head lifting speed(m/min) | Slow speed: 0-0.3 (continuously variable) Fast speed: 11 |
| The effective lifting stroke of the power head（m） | 18 |
| Large feed force(kN) | 40 |
| Drilling angle（°） | 0～90 |
| Drilling tower height（m） | 21 |
| Swinging spray angle（°） | 60 or 90 |
| Swinging frequency (times/min) | 15（adjustable） |
| Swinging spray control method | PC automatic control |
| Electricity machine power（kW） | 7.5+7.5+5.5+0.75 |
| Installation form | Integral |
