型号Model | YSL-300RC | ||
总重量 Drill rig weight(crawler mounted) |
kg | 8500 | |
长x宽x高(运输状态) Length × Width × Height (normal) |
mm | 6750×2300×3000 | |
环境温度 Ambient Temperature Range |
°C | -10~38 | |
名义钻孔深度 Nominal Drill Depth |
m | 300 | |
钻孔直径 Drill Diameter |
mm | 130~350 | |
钻杆动力头Drill head output | |||
输出转速 Output Rotation Speed |
rpm | 55,110 | |
输出扭矩 Max Output Torque |
N.m | 10000 | |
动力头给进Stroke of Power Head | |||
行程 Feeding |
mm | 3500 | |
给进力 Thrust Force |
kN | 100 | |
提拔力 Lifting Capacity |
kN | 150 | |
油泵Oil Pump | |||
油泵排量 Output volume |
ml/r | 63+63+25 | |
液压油Hydraulic Oil | L-HM46 | ||
油箱容积 Tank Capacity |
L | 220 | |
回油过滤精度(名义) Nominal Filtration Particle Size |
μm | 10 | |
动力机Engine drive type | 6BTA5.9-C180 | ||
功率 Power |
kW | 132 | |
转速 Rotary Speed (Max.) |
rpm | 2200 | |
履带底盘Track Chassis Base | PD135XB | ||
行走速度 Walk Speed |
km/h | 2.0 | |
接地比压 Unit Pressure |
MPa | <0.05 | |
爬坡能力 Climb Ability |
度 | ≤20 | |
液压绞车Winch | |||
提升力 Lift Force |
KN | 11 |
